50W 200-6700MHz GaN Anti Drone Fpv Module Anti Drone Jammer Jamming Module
Price range: $250.00 through $320.00
Description
RF Data
| Item | Spec. | Remarks | ||
| Frequency Range(MHz) | 200-6700 | Customizable frequency bands | ||
| Existing frequency bands(MHz) | 200-350/350-500/500-650/650-850
850-1050/1100-1300/1500-1650 2100-2300/2300-2500/2500-2700 5100-5300/5700-5900 |
Bandwidth Range±10MHz |
||
| Working Voltage | 28V | 24-30V | ||
| Analog sweeping speed | 250KHz | |||
| Output Power (Max) | ≥47dBm | 50W | ||
| Gain (Max) | 47±1 dB | |||
| Ripple in Band | ≤ 3dB | Peak | ||
| Bandwidth adjustment | Yes | By screw | ||
| Center adjustment | Yes | By screw | ||
| Enable control | Optional | 24-28V | ||
| Output VSWR | ≤3 | |||
| Working current@+28V dc | ≤5.5A | |||
| High Low Temperature test | Working Temperature | -20~+65ºC | Working properly | |
| Gain Stability | ±1 dB | at -20ºC~+55ºC | ||
| Power stability | ±1 dB | at -20ºC~+55ºC | ||
| Power supply Port | Positive and negative lines | 24-28V; GND | ||
| RF output connector | SMA-Female | |||
| LED indicator light | Power ON/OFF | |||
| Dimension | 120*40*20 mm | |||
| Screw Size | 4-Ø3.20 mm | |||
| Weight | 250g | |||
Additional information
| Weight | 0.25 kg |
|---|---|
| Dimensions | 12 × 4 × 2 cm |
| Frequency Range: | 200-6700MHz |
| Optional frequencies: | Allows custom frequencies |
| Output Power (Max): | 50W |
| Gain (Max): | 47±1 dB |
| Ripple in Band: | ≤ 3dB |
| Bandwidth adjustment: | By screw |
| Center adjustment: | By screw |
| Enable control: | Optional |
| Output VSWR: | ≤3 |
| Working current@+28V dc: | ≤5.5A |
| Working Temperature: | -20~+65ºC |
| RF output connector | SMA-Female |
| Frequency band | 200-350MHz, 350-500MHz, 500-650MHz, 650-850MHz, 850-1050MHz, 1100-1300MHz, 1500-1650MHz, 2100-2300MHz, 2300-2500MHz, 2500-2700MHz, 5100-5300MHz, 5700-5900MHz |
